Laser engraving machine Magic-L3 30W with integrated camera and auto focus

Product information "Laser engraving machine Magic-L3 30W with integrated camera and auto focus"

The L3 laser engraving machine was designed especially for jewelers. The main goal in the development of the L3 was the simple, fast and convenient method for jewelry processing with the laser for everyone. Thanks to the automation functions, the simplicity of the software and the high performance, this has become possible.

Versatile use

The Magic L3-30W can process many materials commonly used in the jewelry industry, including gold, silver, aluminum, brass and stainless steel. The machine can perform various marking techniques and effects such as hatching, contour or blackening.

Features

Positioning of the engraving via an integrated camera with auto-focus (also supports the design of elements, among other things)
Automatic focus for the laser for inside and outside engraving of rings
Quiet operation thanks to adaptable cooling system
Load n' Go docking station for clamping fixtures
Easily switch between machining flat workpieces and rings
The rotary fixture simply slides to the left when needed. This feature ensures shorter setup times.
Mass processing with various marking and cutting options in combination
Mass processing even on materials with multi-level heights
Repeat button for repeating the same operations
Attractive design that also allows placement in customers' field of view

Applications

Deep engravings
Inside and outside of rings and bangles
Names, initials, patterns, barcodes and QR codes
Fingerprints, logos and photos
Flat or cylindrical workpieces

Simple and intuitive handling

The engraving software MagicArt 7 can work with vector graphics in the file formats DXF, PLT, SVG, and DGN as well as with images in the formats JPEG, PNG, and BMP. The software is easy to use via the graphical user interface on the PC and offers various functions for formatting text, graphics, and images. For example, the software can automatically generate consecutive numbers when engraving serial numbers.

Safe and convenient

The chamber of the Magic L3-30W is equipped with a cover that closes automatically before the beginning of the laser process and opens again after completion. This not only ensures work safety, but also reduces the distribution of material particles produced during engraving. The suction set N° 311427 can be connected to the rear of the unit to extract the particles.

The generous laser chamber of the Magic L3-30W allows the processing of workpieces up to 350 x 100 x 170 mm (W x H x D). No fixing is required for flat workpieces. For round engravings, the clamping device N° 311453 is required. The engraving is done with a speed of 4000 mm/s.

The machine is very quiet thanks to the adaptive cooling system, space-saving and has a long service life. There are only low maintenance and repair costs incurred.

Scope of delivery

Laser engraving machine Magic L3-30W
Software MagicArt 7

Please follow the country-specific regulations for handling artificial optical radiation.

Activity: 30 W
Colour: Light gray
Dimensions (H x W x D): 55,6 x 40,4 x 59,0 cm
Material: Stainless steel
Power supply: 100 - 240 V
Product area: Equipment & machines
Reference: L3 30W
Suitable for: Cutting up to 1 mm, Flat engraving, Objects up to 112 x 112 x 100 mm, Ring engraving (holder not included)
Type: Laser engraving machine
Weight (kg): 61.8
